165L Constant Temperature and Humidity Test Chamber , Programmable Environment Test Chamber

165L Constant Temperature and Humidity Test Chamber , Programmable Environment Test Chamber

  • 165L Constant Temperature and Humidity Test Chamber , Programmable Environment Test Chamber
165L Constant Temperature and Humidity Test Chamber , Programmable Environment Test Chamber
Product Details:
Place of Origin: China
Brand Name: Meigaolan
Certification: GB/T2423
Model Number: JHHA-415T
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Delivery Time: TBD
Payment Terms: T/T
Contact Now
Detailed Product Description
Product Name: Constant Temperature And Humidity Test Chamber Condition: New
Inside Capacity: 165 L Temperature Min.: -40 °C
Temperature Max: 150 °C Humidity Range: 10 %~98% RH
High Light:

Constant Temperature and Humidity Test Chamber

,

Programmable Environment Test Chamber

Constant Temperature and Humidity Test Chamber , Programmable Environment Test Chamber



Description of Constant Temperature and Humidity Test Chamber



Temperature and humidity test chamber simulating product under the condition of temperature and humidity combination (high and low temperature operation & storage, temperature cycle, high temperature and high humidity, low temperature and humidity and condensation test, etc.), check whether the adaptability and characteristics of the product itself have changed. Temperature humidity test chamber Need to meet the requirements of international standard (IEC, JIS, GB, MIL...). in order to achieve International quantum measurement procedures consistency (including test steps, conditions, methods). To avoid different cognitive, and reduce uncertainly factors scope of measurement.



Overview and Features of Constant Temperature and Humidity Test Chamber



Model No.: JHH-A-415T



Product performance

●Temperature Range:-40~150℃

●Humidity Range: 10 %~98% RH

●Temperature Accuracy:± 0.2 °C

Heating Time:20 ℃~+150 ℃/ ≤45 min

● Cooling Time:20 ℃~-40 ℃/ ≤45 min

 Inside Dimensions: 550×500×600 mm (W*D*H)

● Outside Dimensions: 850×1400×1550 mm (W*D*H)





Materials:

Shell----Double-sided galvanized steel sheet,Surface spraying with Meigaolan standard color

  (1.5mm)


Inner Side----Stainless steel SUS304 (1.2mm)
Cooled Condenser-----air cooled condenser
165L Constant Temperature and Humidity Test Chamber , Programmable Environment Test Chamber 0

Other Size:


Inner Chamber Size

LX( mm)

D 500 600 800 1000 1000
W 500 500 600 800 1000
H 600 750 850 1000 1000

Outer Chamber Size

L( mm)

D 850 900 1100 1350 1370
W 1410 1450 1540 1820 1942
H 1620 1600 1868 2018 2018

Inner Capacity

(L)

  165 225 408 800 1000










FAQ:

1.Can you ship order to Canada or Australia ?
Yes,we can .We send orders worldwide .
2. What delivery method do you use ? and delivery time ?
We can ship by EMS,DHL,FedEx,UPS,TNT with tracking number. Usual delivery time is 4-7 workdays.
3. What is your payment term?
100% T/T payment before shipment.
4. How can I ask any other question ?
You can contact us online or leave us messages below .



Five advantages of Meigaolan Humidity Test Chamber :

1.Temperature humidity chamber Evaporator no frosting under longtime Low temperature and low humidity running. 2.Automatic control system refrigerant demand save electricity above 30%

3.High heat load tested samples test environment

4.realize 95℃ 95%high temperature and high humidity environment.

5.10% 20 ℃ ultra-low temperature range control ability





165L Constant Temperature and Humidity Test Chamber , Programmable Environment Test Chamber 1
