Conducted Immunity EMC Test System Integration Automated 9kHz-30MHz

Conducted Immunity EMC Test System Integration Automated 9kHz-30MHz

  • Conducted Immunity EMC Test System Integration Automated 9kHz-30MHz
  • Conducted Immunity EMC Test System Integration Automated 9kHz-30MHz
Conducted Immunity EMC Test System Integration Automated 9kHz-30MHz
Product Details:
Place of Origin: China
Brand Name: Meigaolan
Certification: ISO9001:2015
Model Number: JS32-CE
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Contact Now
Detailed Product Description
Functions: Tested, In Full Working Conditions Condition: Pre-Owned
Frequceny: 90kHz-30MHz Test: Automated
Voltage Probe: 9kHz-30MHz Current Probe: 9kHz-80MHz
High Light:

Immunity EMC Test System

,

Automated EMC Test System

,

30MHz Conducted Immunity Test System

Conducted Disturbance Immunity Test System Integration 9kHz-30MHz​



The sum of EMC is not necessarily equal to its parts; any modular electronic device from a complete aircraft down to a mobile phone needs to meet EMC requirements for the device itself, even if all the individual modules are compliant. For the enormous range of types of modular device requiring EMC test, MEIGAOLAN offers extremely flexible and scalable EMC test systems; practically as modular as the devices under test.



Description of Conducted Disturbance Immunity Test System Integration



The conducted disturbance test system is mainly used to measure the electromagnetic interference emitted by EUT to the public connection network through power supply and all kinds of electrical signal port cables under typical working conditions, to determine whether to meet the standard limit requirements. Typical ports include ports that are not limited to power, network, phone, USB, and other devices that are connected to a fixed connection when they are working properly.



Composition of Conducted Disturbance Immunity Test System Integration





Conducted Immunity EMC Test System Integration Automated 9kHz-30MHz 0





No. Name Model Description
1 Test Software JS32-CE Automated test software
2 Receiver N9038A/ESR/ESW 3Hz-44GHz
3 Pulse Limiter VTSD 9561F DC-200MHz,10dB
4 Artificial Network NSLK 8127 RC 90kHz-30MHz, 2X16A
5 ISN CAT5 8158 ISN S8 50μH+5Ω ‖ 50Ω
6 Voltage Probe TK9420+VT9420 9kHz-30MHz
7 Current Probe SW 9605 9kHz-80MHz
8 Capacitive Voltage Probe CVP 9222 9kHz-100MHz




Features
  • Comply with CISPR,EN,GB,FCC,VCCI standard
  • Compatible with receiver of KEYSIGHT/R&S or other brand
  • Support for 9kHz-30MHz test,Intelligent processing of segmented frequency points
  • Support step scan and FFT fast scan (if receiver support)
  • Support for user flexibility in diversifying test requirements
  • Support  for automatic test, complete with one-key
  • Support automatic output of test data, complete report with one-key
Application



Frequency:  9kHz-30MHz

Standards: CISPR32,ANSI C63.4,CISPR 16-1-1,CISPR 16-2-1, GB/T 6113.101,

                   GB/T 6113.102,GB/T 6113.201

Applicable Product Range : ICT/ MME/ ISM  civil product

Receiver
The Keysight N9038A is a standards-compliant MXE EMI test receiver and diagnostic signal analyzer built on an upgradeable platform. You choose the frequency coverage you need to fully test devices with outstanding accuracy and sensitivity across required ranges.
