N5222A Microwave Vector Network Analyzer 10MHz-26.5GHz with 132 dB Dynamic Range and 500,000 Points/s Speed

Name: N5222A Microwave Vector Network Analyzer 10MHz-26.5GHz with 132 dB Dynamic Range and 500,000 Points/s Speed
Brand: Shenzhen Meigaolan Electronic Instrument Co. Ltd
SKU: N5222A
Availability: InStock

Brand Name:	Keysight (Agilent)
Model Number:	N5222A
MOQ:	1 set
Price:	Negotiable
Delivery Time:	1~3 Working Days
Payment Terms:	T/T，Western Union

Detail Information

Product Description

Ratings & Reviews

Detail Information

Place of Origin:

Malaysia

Dynamic Range:

Up To 132 DB

Output Power:

Up To +13 DBm

Power Range:

Up To +38 DBm

Number Of Channels:

200

Measurement Speed:

Up To 500,000 Points/s

Sweep Time:

Up To 0.01 Ms

Display Resolution:

Up To 0.001 DB

Connector Type:

SMA, N, 2.4 Mm, 3.5 Mm

Packaging Details:

Carton

Supply Ability:

In Stock

Highlight:

N5222A Vector Network Analyzer

Microwave Vector Network Analyzer

Product Description

Test Equipment N5222A Microwave Or Vector Network Analyzer 10MHz-26.5GHz

Key Features & Specifications

10 MHz to 26.5 GHz frequency range
2-ports with single source or 4-ports with two built-in sources
127 dB system and 132 dB receiver dynamic range, 32,001 points, 200 channels, 15 MHz IF bandwidth
High output power (+13 dBm) and wide power sweep range (38 dB)
Best dynamic accuracy: 0.1 dB compression with +12 dBm input power at test port
Low noise floor of -114 dBm at 10 Hz IF bandwidth

Product Overview

The PNA Series is the highest-performing microwave network analyzer in the industry for passive and active device testing. Choose from five frequency models (13.5, 26.5, 43.5, 50, or 67 GHz) and customize your PNA with the precise performance level to meet your specific budget and measurement requirements.

The Agilent PNA tests a wide variety of passive and active devices including filters, duplexers, amplifiers, and frequency converters. Its high-performance characteristics make it ideal for component characterization, millimeter-wave, signal integrity, and materials measurements.

The PNA Series provides high-power sources and superior linear receivers, delivering the most accurate S-parameter measurements with the widest power range available.

Overview and Features

Unrivaled excellence in measurements and designs
Transform deeper understanding into better designs with outstanding measurement integrity
Meet toughest measurement challenges with industry's highest performing microwave network analyzer
Best accuracy with Keysight's S-parameter measurements
Customize to exact performance level for specific budget and measurement needs

What's Included

Plug, hole, bottom foot
Installation and quick start guide
Safety manual
Calibration certificate
3 Inductors (ferrite cores)
Wrench
Cable tie
Optical Mouse

Applications

S-parameters (CW and pulsed)
Noise figure
Gain compression
Intermodulation and harmonic distortion
Conversion gain/loss
True-differential stimulus
Millimeter-wave
Material measurements
Signal integrity
Antenna test

Available Options

Option Code	Description
007	Automatic Fixture Removal
008	Pulsed-RF Measurements
010	Time Domain
015	Dynamic Uncertainty for S-Parameter Measurements
020	Add IF inputs
021	Add pulse modulator to internal first source
022	Add pulse modulator to internal second source
025	Add four internal pulse generators
028	Noise figure measurements using standard receivers
080	Frequency-Offset (for use with mixers, converters and amplifiers)
082	Scalar calibrated converter measurements
083	Vector and scalar calibrated converter measurements
084	Embedded LO measurements
086	Gain compression application
087	Intermodulation distortion measurements
088	Source phase control
089	Differential and I/Q devices application
090	Spectrum Analyzer
093	Extended Spectrum Analyzer to 110 GHz
094	Extended Spectrum Analyzer above 110 GHz
118	Fast CW Mode
200	2 ports, single source, base hardware configuration
201	2-Ports, Single Source with Configurable Test Set
210	2 ports, single source, with metrology configuration
217	2-Ports, Single Source, Configurable Test Set with Extended Power Range
219	2-Ports, Single Source, Configurable Test Set, Extended Power Range, Bias-Tees
301	Application for use with standard CalPods
302	Application for use with temperature-characterized CalPods
400	4-Ports, Dual-Source, Base Configuration
401	4-Ports, Dual-Source with Configurable Test Set
417	4-Ports, Dual-Source, Configurable Test Set with Extended Power Range
419	4-Ports, Dual-Source, Configurable Test Set, Bias Tees with Extended Power Range
460	Integrated true-mode stimulus application
551	N-port calibrated measurements
897	Built-in performance test software for inclusive calibration, perpetual license
898	Built-in performance test software for standards compliant calibration, perpetual license
W7X	Windows 7 operating system
WXP	Windows XP operating system
