Keysight (Agilent) DSO80204B 2GHz 4CHANNELS 40GSa/S Infiniium Oscilloscope

Description of Keysight Agilent DSO80204B

• 2GHz Bandwidth
• 4 analog input channels
• Up to 40GSa/s sample rate
• 524kpts of acquisition memory on 2 channels
• 8.4 inch colour TFT-LCD display

• The Keysight Infiniium 80204B oscilloscope is a 4 Channel 2GHz Analog Bandwidth oscilloscope with a maximum sample rate of 40GSa/s.

  The 80204B features an 8.4” XGA colour display, memory depth of 262Kb per channel (expandable to 2M) and up to 4800 waveforms/sec acquisition rate.

  The Keysight Infiniium 80000B series oscilloscopes offers the industry’s widest selection of probe amplifier bandwidths and the industry’s widest variety of different probe head types. InfiniiMax is also the probing system that offers 13 GHz bandwidth for the differential solder-in, differential browsing and differential SMA use models.

Feature of Keysight (Agilent) DSO80204B:

• Keysight (Agilent/HP) DSO80204B
• Keysight (Agilent/HP) DSO80204B 001

List of Options of Keysight (Agilent) DSO80204B:

• DSO80204B - 001 - 2 M (2 CH), 1 M (4 CH) MEMORY UPGRADE,64 M (2 CHANNELS AT 4 GSA/S) OR 32 M (4 CHANNELS = 2 GSA/S)
• DSO80204B - 002 - EZJIT JITTER ANALYSIS SOFTWARE
• DSO80204B - 003 - HIGH-SPEED SERIAL DATA ANALYSIS/MASK TESTING WITH CLOCK RECOVERY AND 8B/10B DECODING
• DSO80204B - 004 - EZJIT PLUS JITTER ANALYSIS SOFTWARE
• DSO80204B - 005 - NOISE REDUCTION SOFTWARE (INCLUDED STANDARD FOR DSO81304B)
• DSO80204B - 006 - MY INFINIIUM INTEGRATION PACKAGE
• DSO80204B - 007 - LOW-SPEED SERIAL DATA ANALYSIS FOR I2C/SPI
• DSO80204B - 008 - LOW-SPEED SERIAL DATA ANALYSIS FOR CAN
• DSO80204B - 009 - INFINIISCAN EVENT IDENTIFICATION SOFTWARE
• DSO80204B - 017 - 40 GB REMOVABLE HARD DISK DRIVE. REPLACES INTERNAL HARD DISK WITH A REMOVABLE HARD DISK.
• DSO80204B - 1CM - RACK-MOUNT KIT
• DSO80204B - N5420G - DSO80204B TO DSO80304B UPGRADE (2 GHZ TO 3 GHZ)
