4GHz 4 Channels Analog Digital Oscilloscope Keysight Agilent DSO9404A

Keysight Agilent DSO9404A Analog Digital Oscilloscope 4 GHz 4 Analog Channels

Description of Keysight Agilent DSO9404A

• Agilent’s Infiniium DSO9404A, equipped with a 15” XGA display, comes in a package that is just 9” (23 cm) deep and weighs only 26 (11.8 kg) pounds to preserve your limited bench space. This scope is engineered to give you the broadest measurement capability available to meet your needs both today and in the future. Add 16 integrated digital channels with the MSO9404A.Take advantage of optional integrated protocol viewers to quickly isolate physical layer issues causing errors. Customize your toolset with our debug and compliance packages to tailor the scope to your needs.

Feature:

Engineered for the broadest measurement capability

• 4 GHz bandwidth across all 4 analog channels
• 20 GSa/s max. sample rate
• Standard 20 Mpts memory per channel, upgradeable to 1 Gpts
• See the Infiniium 9000 Series video demo

Get three instruments in one

• Scope: The powerful features of our Infiniium Series oscilloscopes with InfiniiScan advanced triggering coupled with superior specifications give you precise signal representation
• Logic Analyzer: Add 16 integrated, deep-memory digital channels to see critical data values and timing relationships. Choose MSO9404A
• Protocol analyzer: Choose integrated protocol viewers to quickly drill down into packets and time correlate between protocol and physical layers.

Widest range of debug and compliance software applications

• Serial protocol applications including I²C, SPI, RS-232, CAN, LIN, FlexRay, JTAG, PCI Express, USB 2.0, MIPI D-Phy, SATA and 8B/10B
• Serial physical layer applications including USB 2.0, DDR 1/2/3, Ethernet, and MIPI D-Phy
• Jitter analysis applications including EZJIT and EZJIT Plus
• MATLAB® software available directly from Agilent for making your own custom measurement and analysis routines, user-defined filters, or instrument applications. MATLAB software for Agilent oscilloscopes

​

List of Options
