Audio Precision APX525 High Performance Modular Audio Analyzer

Audio Precision APX525 High Performance Modular Audio Analyzer

  • Audio Precision APX525 High Performance Modular Audio Analyzer
  • Audio Precision APX525 High Performance Modular Audio Analyzer
  • Audio Precision APX525 High Performance Modular Audio Analyzer
  • Audio Precision APX525 High Performance Modular Audio Analyzer
Audio Precision APX525 High Performance Modular Audio Analyzer
Product Details:
Place of Origin: USA
Brand Name: Audio Precision
Certification: CE
Model Number: APX525
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: carton
Payment Terms: T/T
Supply Ability: in stock
Contact Now
Detailed Product Description
Product Name: Audio Analyzer Max Reading Speed: 50,000 Readings/s
Condition: Pre-Owned Functions: Tested, In Full Working Conditions
Form Factor: Benchtop/Rackmount

Audio Precision APX525 High Performance Modular Audio Analyzer

Description of Audio Precision APX525

  • 2 analog input channels
  • AES/SPDIF digital I/O
  • Typical THD+N < -110 dB [with AG52 option]
  • > 1 MHz bandwidth @ 24 bits on two channels [with BW52 option]
  • 1.2 M point FFTs

The APx52x Series of audio analyzers combines an award-winning user interface and legendary performance with a comprehensive range of modular I/O options. The APx52x Series brings AP innovations such as one-click measurements, code-free automation and sophisticated reporting to every interface in every combination.

The APx525 ships with two channels of analog I/O and our Digital Interface Option (DIO) with AES/SPDIF digital inputs and outputs, and includes ASIO capability. If you need more than that, APx525 is ready with a full range of choices, from additional channels of analog to a chip-level digital serial interface (DSIO), HDMI+ARC, PDM (Pulse Density Modulation) or Bluetooth wireless technology with built-in radio.

Need higher analog performance? With the BW52 enhanced analog bandwidth option installed, you can make a million-point FFT spectrum acquisition at 24 bits, across a bandwidth of DC to over 1 MHz on two channels. And with the AG52 enhanced analog generator option, typical system THD+N is as low as 110 dB.

Feature of Audio Precision APX525



The Audio Precision APX525 is fully tested and refurbished in our in-house ISO9001 calibration laboratory. We supply manuals, accessories, full warranty and a free-of-charge Certificate of Conformity. We can also provide the Audio Precision APX525 with a fresh calibration for a small additional charge.





List of Options for Audio Precision APX525
  • Audio Precision APX525
  • Audio Precision APX525 AG52/BW52
  • Audio Precision APX525 AO52/DSIO
  • Audio Precision APX525 DIO/PDM
  • Audio Precision APX525 DIO/PDM/DSIO
Specifications & Attributes Audio Precision APX525
  • APX525 - ADIO - ADVANCED DIGITAL I/O AND ADVANCED MASTER CLOCK MODULES

  • APX525 - AG52 - ANALOG SQUARE WAVE AND DIM GENERATION, HIGHER MAXIMUM OUTPUT AND IMPROVED SYSTEM THD+N

  • APX525 - AMC - ADVANCED MASTER CLOCK ADDS JITTER CLOCK, SYNC AND TRIGGER I/O

  • APX525 - BLUETOOTH - BLUETOOTH RADIO FOR BLUETOOTH AUDIO TEST

  • APX525 - BW52 - TWO CHANNEL, 24-BIT, 1 MHZ BANDWIDTH ANALYSIS

  • APX525 - DIGITAL SERIAL - INTERFACE FOR I2S, TDM, DSP

  • APX525 - DIO - AES / SPDIF DIGITAL I/O (STANDARD ON APX525)

  • APX525 - HDMI+ARC - HDMI SOURCE, SINK, MONITOR, AUX AND ARC I/O

  • APX525 - PDM - DIRECT CONNECTIVITY FOR DIGITAL MEMS MICS



FAQ:

1.Can you ship order to Canada or Australia?
Yes,we can .We send orders worldwide.

2. What delivery method do you use? and delivery time?

We can ship by EMS,DHL,FedEx,UPS,TNT with tracking number. Usual delivery time is 4-7 workdays.

3. What is your payment term?

100% T/T payment before shipment.

4. How can I ask any other question?

You can contact us online or leave us messages below.

Audio Precision APX525 High Performance Modular Audio Analyzer 0Audio Precision APX525 High Performance Modular Audio Analyzer 1Audio Precision APX525 High Performance Modular Audio Analyzer 2Audio Precision APX525 High Performance Modular Audio Analyzer 3
