Logic analyzer configuration

• 68 channels, 350 MHz state, 12.5 GHz timing zoom, 2.5 GHz timing, 2 Mb depth standard
• 15-inch (38.1 cm) color, touch-screen display for viewing and quickly navigating large numbers of signals and buses
• built-in removable SSD drive, USB 3.0 ports, and LAN for fast data transfer and storage of large amounts of data
• 1.4 GHz trigger sequencer to ensure high-speed events are captured

Timing analysis (asynchronous sampling)

• up to 2.5 GHz/5.0 GHz/10 GHz (full-/half-/quarter-channel) timing for capturing signal activity at high resolution
• up to 128 Mb/256 Mb/512 Mb (full-/half-/quarter-channel) deep memory for identifying the root cause of a problem and symptom widely separated in time
• 12.5 GHz (80 ps) timing zoom with 256K memory depth for analysis of the trigger event with high resolution

State analysis (synchronous sampling)

• state data rates up to 1.4 Gb/s, state clock rates up to 700 MHz for high-speed data capture
• automated threshold/sample position setup for accurate measurements on high-speed buses
• simultaneous eye diagrams on all channels for quick identification of problem signals

Configuration considerations (probes and additional software ordered separately)

• select from a wide variety of single-ended and differential general-purpose and application-specific probes
• add application software for insight to debug, analyze, and optimize your system’s operation
• includes keyboard, mouse, accessories bag, power cord, and 3-year warranty

Options of Keysight 16862A 68-Channel Portable Logic Analyzer
