Product Name: Vector Network Analyzer (VNA) Frequency: From 9 KHz To 3 GHz/6 GHz/13.6 GHz
Form Factor: Portable Type: Vector Network Analyzer (VNA)
Condition: Pre-Owned Functions: Tested, In Full Working Conditions
High Light:

Multipurpose Portable Network Analyzer

,

Rohde Schwarz VNA Portable Network Analyzer

Rohde and Schwarz ZVL3 Vector Network Analyzer 9 kHz to 13.6 GHz
Description of Rohde and Schwarz ZVL3
Cost-efficient, powerful, future-proof – the all-in-one solution in the compact class:
  • Network analyzer
  • Complete spectrum analyzer (optional)
  • Unrivaled price/performance ratio
  • Versatile applications in development, production, service, and installation
  • Universal RF analysis due to three instruments in a single box:
    • Bidirectional two-port vector network analyzer: measurement of all four S-parameters
    • Full-featured optional spectrum analyzer
    • Highly accurate optional power meter (in SPA mode, together with an R&S®NRP-Z power sensor)
  • Wide variety of options enhancing application range of optional spectrum analyzer
    • Application firmware for component and signal analysis, e.g.: noise figure and gain measurements, AM/FM/PM demodulation, spectrogram display, analysis of TV signals
    • Application firmware for various digital communications standards such as: WCDMA, WLAN, WiMAX, Bluetooth®
    • For more information, go to option site
  • Compact, portable, and lightweight at less than 7 kg; optional battery operation
  • DVI-D monitor interface

Key Features:

  • Frequency Range: 9 kHz to 3 GHz
  • Wide Dynamic Range: Up to 140 dB
  • Measurement Speed: Very fast sweep times
  • Vector Network Analyzer (VNA) Capabilities:
    • S-parameters (S11, S21, S12, S22)
    • Impedance measurements
    • Smith chart display
  • Spectrum Analyzer Mode:

                Frequency range: 9 kHz to 3 GHz

                FFT-based time domain analysis

  • Power Measurement: Option for power measurements up to 6 GHz
  • Portability: Compact size and lightweight

Additional Features:

  • Interfaces:
    • USB, LAN, GPIB
    • VGA output
  • Measurement Modes:
    • Reflection and transmission measurements
    • Distance to Fault (DTF) analysis
  • Calibration:
    • Manual and automatic calibration options
  • Data Analysis:
    • Marker functions
    • Limit testing
    • Data saving and recall

Applications:

  • RF Component Testing
  • Antenna Testing
  • Filter Characterization
  • Cable and Connector Testing
  • Amplifier Characterization
  • Production Testing
  • Education and Training




List of Options
B10 GPIB interface
B22 RF preamplifier gain 20 dB
B30 DC power supply 12 - 28 V
B31 NiMH battery pack
B4 OCXO reference frequency
B5 Additional interfaces video/IF-output, power meter 28 V - DC for noise source
B6 TV trigger for FSL and for ZVL with ZVL-
B7 Narrow resolution filters 10 Hz - 300 Hz
B8 Gated sweep function for FSL and for ZVL with ZVL-K1
C3 Three years of depot calibration coverage based on the R&S recommended calibration interval - includes test data. The first calibration is included with product delivery with 2 additional depot calibration(s).
C5 Five years of depot calibration coverage based on the R&S recommended calibration interval - includes test data. The first calibration is included with product delivery with 4 additional depot calibration(s).
DCV-1 Documentation of calibration values
DCV-ZP Printout of DCV (additional, in combination with DCV-Option only)
EVS-Z6 Accessory: Protective hard cover (for EVS300, FSL, ZVL)
FSL-B10 GPIB interface
FSL-B22 RF preamplifier, gain 20 dB (software license)
FSL-B30 DC power supply 12 - 28 V
FSL-B31 NiMH battery pack
FSL-B4 OCXO reference frequency
FSL-B5 Additional interfaces video/IF-output, power meter 28 V - DC for noise source
FSL-B6 TV trigger (for R&S®FSL and R&S®ZVL w. R&S®ZVL-K1) (software license)
FSL-B7 Narrow resolution filters, 10 Hz - 300 Hz (software license)
FSL-B8 Gated sweep function (for R&S®FSL and R&S®ZVL w. R&S®ZVL-K1) (software license)
FSL-K14 Spectrogram measurement, application firmware (for R&S®FSL and R&S®ZVL w. R&S®ZVL-K1)
FSL-K20 Application firmware for cable TV and TV measurements (software license)
FSL-K30 Application firmware for noise figure and gain measurements (for R&S®FSL and R&S®ZVL w. R&S®ZVL-K1)
FSL-K7 Analogue demodulation AM/FM/PM (for R&S®FSL and R&S®ZVL w. R&S®ZVL-K1) (software license)
FSL-K72 3GPP Code Domain Power measurements for base station (for R&S®FSL and R&S®ZVL w. R&S®ZVL-K1)
FSL-K8 Application firmware for TX measurements acc. to Bluetooth v. 1.1 and 2.0 (EDR) (for R&S®FSL and R&S®ZVL w. R&S®ZVL-K1)
FSL-K9 Power sensor measurements with NRP (software license)
FSL-K91 Application firmware for WLAN 802.11A,B,G measurements (for R&S®FSL and R&S®ZVL w. R&S®ZVL-K1)
FSL-K93 Application Firmware for WIMAX# 802.16 OFDM/OFDMA Measurements (for R&S®FSL and R&S®ZVL w. R&S®ZVL-K1)
FSL-Z3 Soft carrying bag
FSL-Z4 Additional charger unit for FSL-B31. Allows charging the battery without FSL
K1 Spectrum analysis function (for ZVL3, ZVL6, ZVL13)
K14 Spectrogram measurement, application firmware for FSL and for ZVL with ZVL-K1
K2 Distance to Fault Measurement (for ZVL3, ZVL6, ZVL13)
K20 Analog and digital cable TV measurements
K3 Time Domain analysis (for ZVL3, ZVL6, ZVL13)
K30 Application firmware for noise figure and gain measurements for FSL and for ZVL with ZVL-K1
K7 Analogue demodulation AM/FM/PM for FSL and for ZVL with ZVL-K1
K72 3GPP Code Domain Power measurements for base station for FSL and for ZVL with ZVL-K1
K8 Application firmware for TX measurements acc. to Bluetooth v. 1.1 and 2.0 (EDR) for FSL and for ZVL with ZVL-K1
K9 Power sensor measurements with NRP
K91 Application firmware for WLAN 802.11A,B,G measurements for FSL and for ZVL with ZVL-K1
K93 Application Firmware for WIMAX 802.16 OFDM/OFDMA Measurements for FSL and for ZVL with ZVL-K1
NRP-Z11 Average power sensor for universal use, 10 MHz - 8 GHz, 200 pW - 200 mW,
NRP-Z21 Average power sensor for universal use 10 MHz - 18 GHz, 200 pW - 200 mW,
NRP-Z22 Average power sensor 10 MHz - 18 GHz, 2 nW - 2 W for universal use,N(m)
NRP-Z23 Average power sensor 10 MHz - 18 GHz, 20 nW - 15 W for universal use, N(m)
NRP-Z24 Average power sensor 10 MHz - 18 GHz, 60 nW - 30 W for universal use, N(m)
NRP-Z51 Thermal power sensor 0 - 18 GHz, 1 µW - 100 mW, N(m)
NRP-Z55 Thermal power sensor 0 - 40 GHz, 1 µW - 100 mW, 2.92mm(m)
NRP-Z91 Average power sensor 9 kHz - 6 GHz, 200 pW - 200 mW, N(m)
R3 Three years of depot repair coverage, including re-calibration if necessary to complete the repair. First year of repair coverage is provided by the 12-month new product warranty.
R5 Five years of depot repair coverage, including re-calibration if necessary to complete the repair. First year of repair coverage is provided by the 12-month new product warranty.
RAM Matching pad 50/75 Ohm, 0 - 2700 MHz, matching at both ends, N-connectors
RAZ Matching pad 50/75 Ohm, 0 - 2700 MHz, matching at one end, N-connectors
ZCAN Calibration kit, type N, 75 Ohm, 0-3 GHz precision load, short/open and through N-male and N-female
ZRC SWR bridge 50 Ohm 40 kHz - 4 GHz, calibration standard incl. test port connector N female
ZV-Z191 RF Cable 50 Ohm; N(m) to N(m); DC to 18GHz, flexible, phase stable; 610mm (24 inch)
ZV-Z191 RF Cable 50 Ohm; N(m) to N(m); DC to 18GHz, flexible, phase stable; 910mm (36 inch)
ZV-Z192 RF Cable 50 Ohm; N(m) to PC3.5mm(m); DC to 18GHz, flexible, phase stable; 610mm (24 inch)
ZV-Z192 RF Cable 50 Ohm; N(m) to PC3.5mm(m); DC to 18GHz, flexible, phase stable; 910mm (36 inch)
ZV-Z21 Calibration kit N, 50 Ohm TOSM 0 - 18 GHz
ZV-Z235 Calibration kit 3.5mm, 0 Hz to 26 GHz, Open, Short, Match, through m/f each
ZV-Z33 3.5mm calibration kit with sliding matches 0 - 26.5 GHz certificated acc.
ZV-Z91 Flexible Precision Cable 50 Ohm N(m)/N(m); DC to 18 GHz; 635mm (25 inch); 1 piece
ZV-Z91 Flexible Precision Cable 50 Ohm N(m)/N(m); DC to 18 GHz; 965mm (38 inch); 1 piece
ZV-Z92 Flexible Precision Cable 50 Ohm; N(m)/3.5mm(m) DUT; DC to 18 GHz; 635mm(25 inch); 1 piece
ZV-Z92 Flexible Precision Cable 50 Ohm; N(m)/3.5mm(m) DUT; DC to 18 GHz; 965mm(38 inch); 1 piece
ZZA-211 19" adapter, 2 HU, 1/1 for BW2000 cabinets
ZZA-97 19" adapter 2 HU, 1/2 for KB 90 cabinets, for 1 or 2 units 350 mm depth / NRVS, URV35/55
ZZA-98 19" adapter 2 HU/3 HU, ½ wide, for KB90 cabinets, 2 HU and 3 HU combinable, 350 mm depth/ NRVD
ZZA-S334 Adapter for BW2000 3HU 3/4 cabinet with impact protection
ZZA-T26 19" adapter 1/2 type 26
ZZA-T27 19" adapter 1/2 type 27
