Keysight Agilent N8737A 60v Dc Power Supply 55A 3300W Programmable

Keysight Agilent N8737A 60v Dc Power Supply 55A 3300W Programmable

  • Keysight Agilent N8737A 60v Dc Power Supply 55A 3300W Programmable
  • Keysight Agilent N8737A 60v Dc Power Supply 55A 3300W Programmable
  • Keysight Agilent N8737A 60v Dc Power Supply 55A 3300W Programmable
  • Keysight Agilent N8737A 60v Dc Power Supply 55A 3300W Programmable
  • Keysight Agilent N8737A 60v Dc Power Supply 55A 3300W Programmable
  • Keysight Agilent N8737A 60v Dc Power Supply 55A 3300W Programmable
Keysight Agilent N8737A 60v Dc Power Supply 55A 3300W Programmable
Product Details:
Place of Origin: Malaysia
Brand Name: Keysight (Agilent)
Certification: ISO:17025 Accredited Calibration
Model Number: N8737A
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Payment Terms: T/T
Supply Ability: in stock
Contact Now
Detailed Product Description
Product Name: DC Power Supply Form Factor: Benchtop/Rackmount ( N5740A )
Current: 55A Power: 3300 W
Condition: Pre-Owned Functions: Tested, In Full Working Conditions
Voltage: 60V Type: SWITCHING
High Light:

60v Dc Power Supply 55A

,

Programmable 60v Dc Power Supply

,

3300W Programmable Dc Power Supply

Keysight Agilent N8737A DC Power Supply 60V 55A 3300W Programmable



Description of  Keysight Agilent N8737A



Agilent basic DC power supplies offer essential features for a tight budget. The Agilent N8737A is a 60V, 55A, 3300W, single output power supply in a small 2U package. It offers flexible AC input options, analog/resistance control of output voltage and current, as well as parallel and series connection of multiple supplies to achieve more output current or voltage respectively.

Please select the AC input voltage option carefully. The AC input voltage hardware is permanently installed at the factory and cannot be changed under any circumstances after delivery.

If the wrong AC input voltage option is purchased and delivered, the unit would need to be returned. Product returns are subject to Agilent approval and applicable charges. A new order would then have to be placed.



Highlights of N8737A DC Power Supply



The Keysight Technologies, Inc. N8700 series system DC power supplies give you just the right performance — at just the right price — in a compact (2 U) package. This family of affordable 3300 W and 5000 W single-output programmable DC power supplies consists of 21 models for simple DC power applications. They provide stable output power, built-in voltage and current measurement, and output voltage and current from 8 V to 600 V and 5.5 A to 400 A. These economical supplies offer many system-ready features like multiple standard I/O interfaces to simplify and accelerate test-system development for R&D, design validation, and manufacturing engineers in the aerospace/defense, automotive, component, and communications industries.



Output Ripple and Noise

  • CV p-p: 60mV
  • CV rms: 8mV

DC Output Ratings

  • Voltage: 60V
  • Current: 55A
  • Power: 3300W

Programming Accuracy

  • Voltage: 0.05% + 30mV
  • Current: 0.1% + 110mA

Keysight Agilent N8737A 60v Dc Power Supply 55A 3300W Programmable 0

List of Options



208 DC Power Supply 190V-240V, 3 phase AC, 50/60Hz INPUT (use with LINE CORD OPT 861)
230 DC Power Supply 190V-240V, 1 phase AC, 50/60Hz INPUT (use with LINE CORD OPT 831 or 832)
400 DC Power Supply 380V-415V, 3 phase AC, 50/60Hz INPUT (use with LINE CORD OPT 862)
831 Power cord, USA, No Plug, 10awg, 3-wire, 8ft (Input 230VAC 1 phase)
832 Power cord, Europe, no plug, 4mm, 3-wire, 2.5m
861 Power cord, USA, No Plug, 10awg, 4-wire, 8ft (Input 208VAC 3 phase)
862 Power cord, Europe, No Plug,2.5mm, 4-wire,2.5M (Input 400VAC 3 phase)
N5740A Rack-mount Slide Kit
R-50C-011-3 Agilent Calibration - 3 years
R-50C-011-5 Agilent Calibration - 5 years
R-50C-021-3 ANSI Z540-1-1994 Calibration - 3 years
R-50C-021-5 ANSI Z540-1-1994 Calibration - 5 years
R-51B-001-3C Return to Agilent Warranty - 3 years
R-51B-001-5C Return to Agilent Warranty - 5 years
R-51B-001-C Return to Agilent Warranty - 1 year



FAQ:
1.Can you ship order to Canada or Australia ?
Yes,we can .We send orders worldwide .
2. What delivery method do you use ? and delivery time ?
We can ship by EMS,DHL,FedEx,UPS,TNT with tracking number. Usual delivery time is 4-7 workdays.
3. What is your payment term?
100% T/T payment before shipment.
4. How can I ask any other question ?
You can contact us online or leave us messages below .



Keysight Agilent N8737A 60v Dc Power Supply 55A 3300W Programmable 1Keysight Agilent N8737A 60v Dc Power Supply 55A 3300W Programmable 2Keysight Agilent N8737A 60v Dc Power Supply 55A 3300W Programmable 3Keysight Agilent N8737A 60v Dc Power Supply 55A 3300W Programmable 4Keysight Agilent N8737A 60v Dc Power Supply 55A 3300W Programmable 5
