Electronic Test And Measurement Equipment
Created with Pixso. Keysight Agilent L4445A Microwave Switch / Attenuator Driver Fast Delivery

Keysight Agilent L4445A Microwave Switch / Attenuator Driver Fast Delivery

Brand Name: Keysight (Agilent)
Model Number: L4445A
MOQ: 1 set
Price: Negotiation
Payment Terms: T/T
Detail Information
Place of Origin:
Malaysia
Certification:
ce
Product Name:
Microwave Switch/Attenuator Driver
Form Factor:
Rackmount
Measurement Frequency Range:
50 MHz
Condition:
Pre-Owned
Functions:
Tested, In Full Working Conditions
Color:
Grey
Packaging Details:
carton
Supply Ability:
in stock
Highlight:

Keysight Agilent Microwave Switch

,

L4445A Microwave Switch

Product Description

Keysight (Agilent) L4445A Microwave Switch/Attenuator Driver



Description
The Agilent L4445A provides digital outputs to control switches, attenuators and other devices. The outputs can also be used to drive LEDs that to indicate the switch position. Digital inputs can be used to read back the actual position of the switch or attenuator. The L4445A provides power and control signals for many of the most popular microwave switches and attenuators.

The Y1150A-Y1155A distribution boards enable ease of wiring to the external switches. One L4445A with accessories can drive up to 64 switch coils, that´s 32 SPDT switches. The L4445A supports extended channels with additional 34945EXTs.

Also consider the 34980A 8-slot switch/measure unit that allows you to mix and match different modules into a low-cost, compact solution.


Features:
  • LXI Class C compliance includes built-in Ethernet connectivity
  • Fully-featured graphical web interface
  • Control of most popular microwave switches and attenuators
  • Expandable with 34945EXT
  • Distribution boards for ease of wiring
  • Switch read back capabilities
  • External power option for simultaneous switching
  • Software drivers for most common programming environments
List of Options
34945EXT Extender board for 34945A and L4445A, 1 required for each 64 coils
34945EXT-ATO Extender Driver for 34945A, 1 required for each 64 coils
GPIB Add GPIB
R-51B-001-3C Return to Agilent Warranty - 3 years
R-51B-001-5C Return to Agilent Warranty - 5 years
R-51B-001-C Return to Agilent Warranty - 1 year
Y1150A Distribution Board for 8 (N181x SPDT Switches)
Y1151A Distribution board for 2 (87104x/106x L7x0xx multiport or 87406B) matrix switches
Y1152A Distribution Board for 87204/206x or 87606B Switch and 2 (N181x Switches)
Y1153A Distribution board for 2 (84904/5/6/7/8 or 8494/5/6) step attenuators
Y1154A Distribution board for 2 (87222, L7222C) transfer switches and 6 (N181x SPDT switches)
Y1155A Distribution Board with Screw Terminals for Driving 16 Switch Coils
Y1160A Rack Mount kit for 2 x L44xx series instruments



Keysight Agilent L4445A Microwave Switch / Attenuator Driver Fast Delivery 0Keysight Agilent L4445A Microwave Switch / Attenuator Driver Fast Delivery 1Keysight Agilent L4445A Microwave Switch / Attenuator Driver Fast Delivery 2Keysight Agilent L4445A Microwave Switch / Attenuator Driver Fast Delivery 3

FAQ:

1.Can you ship order to Canada or Australia ?

Yes,we can .We send orders worldwide .

2. What delivery method do you use ? and delivery time ?

We can ship by EMS,DHL,FedEx,UPS,TNT with tracking number. Usual delivery time is 4-7 workdays.

3. What is your payment term?

100% T/T payment before shipment.

4. How can I ask any other question ?

You can contact us online or leave us messages below .
