Anritsu MS2721B Portable Handheld Spectrum Analyzer 9kHz to 7.1GHz option 20

Anritsu MS2721B Portable Handheld Spectrum Analyzer 9kHz to 7.1GHz option 20

Description of Anritsu MS2721B

The MS2721B handheld spectrum analyzer is designed to conduct highly accurate analysis on the new wave of wireless LAN and cellular signals, including 802.11a, 3G, ultra-wideband, WiMAX, and wireless medical patient monitoring systems.

The MS2721B is ideal for AM and FM broadcast proofing because the wide dynamic range and low phase noise make NRSC measurements on analog and IBOC signals easy with no need for an external carrier notch filter.

The MS2721B is a small and easy to use portable spectrum analyzer with unprecedented measurement capability for applications up to 7.1 GHz. Weighing in at less than 7 pounds.The tracking generator option delivers specified performance from 400 kHz to 7.1 GHz. A GPS receiver can be added to allow measurements to location-stamped and to greatly improve time base accuracy. Another option adds spectrogram, signal strength and RSSI.

There is an option to add a user definable channel scanner option that is excellent for interference mitigation work in complicated RF environments. Several smart measurements are built into the MS2721B, including channel power, adjacent channel power ratio, Carrier to Interference ratio. and field strength. In addition, an AM/FM/SSB demodulator is included. Demodulated signals can be monitored using the internal speaker or by using a universal 2.5 mm 3-wire headset, such as used with many cellular telephones.

The MS2721B spectrum analyzer has low phase noise of -100 dBc/Hz 10 kHz offsets, best in its class typical DANL of -163 dBm in a 1 Hz RBW, resolution bandwidth (RBW) range of 1 Hz to 3 MHz and video bandwidth (VBW) range of 1 Hz to 3 MHz. It also has the fastest sweep speeds of any spectrum analyzer in its class. It automatically sets the fastes possible sweep speed consistant with accuracte measurement results.

The use of Compact Flash memory modules or USB Flash Drives up to 512 MB allows an unlimited number of traces and setups to be stored. Measurements may be stored directly to the compact flash module or the USB Flash drive. A512 MB module will hold over 20,000 Spectrum Analyzer measurements. Remote programming using the Ethernet 10/100 Base-T connection is provided using SCPI programming. The Ethernet connection gives the user flexibility in remotely operating the instrument using Anritsu's remote access software, shipped with the product. Measurements and setups may be uploaded and downloaded using either the Ethernet or the USB connection.

Application Software

1x - EVDO ( /34 /62 /63 )

CDMA2000 ( /33 )

CDMAONE ( /33 )

GSM with Edge ( /41 )

HSDPA ( /65 )

Phase Noise

List of Options
