Keysight Agilent N5244A PNA-X Vector Network Analyzer 10 MHz- 43.5GHz

Keysight Agilent N5244A PNA-X Vector Network Analyzer 10 MHz- 43.5GHz

  • Keysight Agilent N5244A PNA-X Vector Network Analyzer 10 MHz- 43.5GHz
  • Keysight Agilent N5244A PNA-X Vector Network Analyzer 10 MHz- 43.5GHz
  • Keysight Agilent N5244A PNA-X Vector Network Analyzer 10 MHz- 43.5GHz
  • Keysight Agilent N5244A PNA-X Vector Network Analyzer 10 MHz- 43.5GHz
  • Keysight Agilent N5244A PNA-X Vector Network Analyzer 10 MHz- 43.5GHz
Keysight Agilent N5244A PNA-X Vector Network Analyzer 10 MHz- 43.5GHz
Product Details:
Place of Origin: Malaysia
Brand Name: Keysight Agilent
Model Number: N5244A
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Carton
Delivery Time: 1~3 working days
Payment Terms: T/T,Western Union, MoneyGram
Contact Now
Detailed Product Description
IF Output: 50 Ω, 0 DBm Display Modes: Normal, Max Hold, And Average
Accuracy: ±1.5 DB Dynamic Range: >110 DB
Trigger Modes: Free Run, External, Video, Pulse, And Timeout Resolution Bandwidth: 1 Hz To 1 MHz
Measurements: Peak, Average, And Quasi-peak Frequency Range: 10 MHz- 43.5GHz

Product Description:

World´s widest range of single-connection measurement applications

The PNA-X network analyzer is the world´s most integrated and flexible single-connection microwave test engine for measuring active devices such as amplifiers, mixers, and frequency converters. You can choose from five frequency models to meet your specific device test needs: 13.5, 26.5, 43.5, 50, and 67 GHz. The PNA-X provides unrivaled configurability with a built-in second source, combiner, and internal signal-routing switches.



Features:

  • 10 MHz to 43.5 GHz
  • 2- or 4-ports with two built-in sources
  • 126 dB system and 129 receiver dynamic range, 32,001 points, 32 channels, 5 MHz IF bandwidth
  • High output power (+16 dBm), low harmonics (-60 dBc) and a wide power sweep range (41 dB)
  • Best dynamic accuracy: 0.1 dB compression with +15 dBm input power at the receiver
  • Low noise floor of -111 dBm at 10 Hz IF bandwidth


Applications:

  • S-parameters (CW and pulsed)
  • Noise figure
  • Gain compression
  • Intermodulation and harmonic distortion
  • Conversion gain/loss
  • True-differential stimulus
  • Millimeter-wave
  • Nonlinear waveform and X-parameter® characterization
  • Antenna test

''X-parameters'' is a registered trademark of Agilent Technologies. The X-parameter format and underlying equations are open and documented. For more information X-Parameters Open Documentation, Trademark Usage & Partnerships



List of Options:

008 Pulsed-RF Measurements
010 Time-domain measurements
020 Add IF inputs
021 Add pulse modulator to internal first source
022 Add pulse modulator to internal second source
025 Add four internal pulse generators
028 Noise figure measurements using standard receivers
080 Frequency offset measurements
081 Reference Channel Switch (Adds internal switch to R1 Path)(Standard Option w/080)
082 Scalar calibrated converter measurements
083 Vector and scalar calibrated converter measurements
084 Embedded LO measurements
086 Gain compression measurements
087 Intermodulation distortion measurements
088 Source phase control
118 Fast CW mode
1A7 ISO 17025 compliant calibration
1CM Rack mount kit for installation without handles
1CP Rack mount kit for installation with handles
200 2 ports, single source
219 Add extended power range and bias-tees to 2 port analyzer
224 Add internal second source, combiner and mechanical switches to 2-port analyzer
29 Corrected noise figure measurements
301 Application for use with standard CalPods
302 Application for use with temperature-characterized CalPods
400 4 ports, dual source
417 4-port dual source extended power range
419 Add extended power range and bias-tees to 4 port analyzer
423 Add internal combiner and mechanical switches to 4-port analyzer
460 Integrated true-mode stimulus application
510 Nonlinear component characterization
514 Nonlinear x-parameters
518 Nonlinear pulse envelope domain
520 Arbitrary load impedance X-parameters
551 N-port calibrated measurements
897 Built-in performance test software for Agilent inclusive calibration, perpetual license
898 Built-in performance test software for standards compliant calibration, perpetual license
A6J ANSI Z540 compliant calibration
H85 Removes bias tees between source attenuators and test port couplers
N1966A Pulse/IO Adapter
N8981A Spare hard drive for use with 1.1 GHz Pentium M CPU board Recommended for use in secure environments
PS-S10 Remote scheduled productivity assistance. Select 1 to 999 hours.
PS-S20 Startup assistance
PS-S20-01 Recommended Startup assistance
PS-T10-PNA PNA operator training for 8 students at the customer's site , H7215B-203
PS-T12-PNA PNA programming for 8 students at the customer's site , H7215B-204
R-50C-011-3 Agilent Calibration - 3 years
R-50C-011-5 Agilent Calibration - 5 years
R-50C-016-3 ISO 17025 Compliant Calibration - 3 years
R-50C-016-5 ISO 17025 Compliant Calibration - 5 years
R-50C-021-3 ANSI Z540-1-1994 Calibration - 3 years
R-50C-021-5 ANSI Z540-1-1994 Calibration - 5 years
R-50J-001-3 Onsite System Verification - 3 years
R-50U-001-3 Onsite Agilent Calibration - 3 years
R-50U-002-3 Onsite ANSI Z540-1-1994 Calibration - 3 years
R-51B-001-3C Return to Agilent Warranty - 3 years
R-51B-001-5C Return to Agilent Warranty - 5 years
R-51B-001-C Return to Agilent Warranty - 1 year
R-51C-001-1CU Onsite Warranty - 1 year
R-51C-001-3CU Onsite Warranty - 3 years
UK6 Commercial calibration certificate with test data

FAQ:

Q1: What is a RF Spectrum Analyzer?
A: A RF Spectrum Analyzer is an instrument used for measuring the amplitude of a signal as a function of frequency. It is mainly used for measuring the power of the spectrum of known and unknown signals.
Q2: What is the model number of the RF Spectrum Analyzer?
A: The model number is N5244A and it is manufactured by Keysight Agilent.
Q3: Where is the RF Spectrum Analyzer made?
A: The RF Spectrum Analyzer is made in Malaysia.
Q4: What is the minimum order quantity for the RF Spectrum Analyzer?
A: The minimum order quantity for the RF Spectrum Analyzer is 1 set.
Q5: What type of packaging is used for the RF Spectrum Analyzer?
A: The RF Spectrum Analyzer is packaged in a carton.
