Tektronix DPO4054B Digital Phosphor Oscilloscope, 500MHz, 2.5GS/s, 20M Record Length, 4 ch
Wave Inspector Navigation and Search
Comprehensive Features Speed Every Stage of Debug
The DPO4054B offers a robust set of features to speed every stage of debugging your design — from quickly discovering an anomaly and capturing it, to searching your waveform record for the event and analyzing its characteristics and your device's behavior.
Digital Phosphor Technology
The DPO4054B's digital phosphor technology provides you with fast insight into the real operation of your device. Its fast waveform capture rate — greater than 50,000 wfm/s — gives you a high probability of quickly seeing the infrequent problems common in digital systems: runt pulses, glitches, timing issues, and more. Waveforms are superimposed with one another and waveform points that occur more frequently are intensified. This quickly highlights the events that over time occur more often or, in the case of infrequent anomalies, occur less often.
Accurate High-speed Probing
The TPP0500 probes, included standard with every DPO4054B oscilloscope, provides 500 MHz of analog bandwidth, and less than 4 pF of capacitive loading. The extremely low capacitive loading minimizes adverse affects on your circuits and is more forgiving of longer ground leads. And, since the probe bandwidth matches your oscilloscope bandwidth, you can see the high-frequency components in your signal which is critical for high-speed applications. The TPP0500 probe, one of the TPP Series of passive voltage probes, offers all the benefits of general-purpose probes like high dynamic range, flexible connection options, and robust mechanical design, while providing the performance of active probes.
Serial Triggering and Analysis (Optional)
On a serial bus, a single signal often includes address, control, data, and clock information. This can make isolating events of interest difficult. The DPO4054B offers a robust set of tools for debugging serial buses with automatic trigger, decode, and search for I2C, SPI, USB, Ethernet, CAN, LIN, FlexRay, RS-232/422/485/UART, MIL-STD-1553, and I2S/LJ/RJ/TDM.
Power Analysis (Optional)
The MSO/DPO4000B Series optional power analysis tools greatly simplify these tasks, enabling quick and accurate analysis of power quality, switching loss, harmonics, safe operating area (SOA), modulation, ripple, and slew rate (di/dt, dv/dt).
Limit/Mask Testing (Optional)
The DPO4054B offers both limit and mask testing capability useful for long-term signal monitoring, characterizing signals during design, or testing on a production line. A robust set of telecommunications and computer standards are provided. Additionally, custom masks can be created and used for characterizing signals.
TekVPI Probe Interface
The TekVPI probe interface sets the standard for ease of use in probing. In addition to the secure, reliable connection that the interface provides, TekVPI probes feature status indicators and controls, as well as a probe menu button right on the compensation box itself. This button brings up a probe menu on the oscilloscope display with all relevant settings and controls for the probe. The TekVPI interface enables direct attachment of current probes without requiring a separate power supply. TekVPI probes can be controlled remotely through USB, GPIB, or LAN, enabling more versatile solutions in ATE environments.
The DPO4054B Includes:
One TPP0500 (500 MHz, 10X, 3.9 pF) passive voltage probe per analog channel, Front Cover (200-5130-xx), User Manual (071-2810-xx), Documentation CD (063-4300-xx), OpenChoice® Desktop Software, NI LabVIEW SignalExpress Tektronix Edition Software, Calibration Certificates document measurement traceability to National Metrology Institute(s) — the Quality System this product is manufactured in is ISO9001 registered, power cord, accessory bag (016-2029-xx) and a three-year warranty.
List of Options
| A0 | North America |
| A1 | Universal EURO |
| A10 | China |
| A11 | India |
| A12 | Brazil |
| A2 | United Kingdom |
| A3 | Australia |
| A5 | Switzerland |
| A6 | Japan |
| A99 | No Power Cord or AC Adapter |
| C3 | Calibration Service 3 Yrs. Provides traceable or functional verification events whichever are applicable to the Product. Cals are at Tektronix recommended interval during the coverage period. Cal coverage includes the Manufactures Cal + 2 a |
| C5 | Calibration Service 5 Yrs. Provides traceable or functional verification events whichever are applicable to the Product. Cals are at Tektronix recommended interval during the coverage period. Cal coverage includes the Manufactures Cal + 4 a |
| D1 | Calibration Data Report |
| D3 | Calibration Data Report 3 Years (with Option C3) |
| D5 | Calibration Data Report 5 Years (with Option C5) |
| DDU | Distribution Demo Unit |
| E1 | English, German, and French manuals and power cords |
| G3 | Three Year Gold Care Plan. Includes expedited repair of all product failures including ESD and EOS, access to a loaner product during repair or advanced exchange to reduce downtime, priority access to Customer Support among others |
| G5 | Five Year Gold Care Plan. Includes expedited repair of all product failures including ESD and EOS, access to a loaner product during repair or advanced exchange to reduce downtime, priority access to Customer Support among others |
| L0 | English Manual |
| L1 | French Manual |
| L10 | Russian Manual |
| L2 | Italian Manual |
| L3 | German Manual |
| L4 | Spanish Manual |
| L5 | Japanese Manual |
| L6 | Portuguese Manual |
| L7 | Simple Chinese Manual |
| L8 | Standard Chinese Manual |
| L9 | Korean Manual |
| L99 | No Manual |
| R5 | Repair Service 5 Years (including warranty) |
| R5DW | Repair service coverage 5 years (includes product warranty period); 5 year period starts at time of customer instrument purchase |
Our service
One-stop service from manufacture to shipping.
1. Your inquiry related to our products or prices will be replied in 24hours.
2. Well-trained and experienced staffs to answer all your enquires influent English.
3. Distributor ship is offered for your unique desigh and some our current models.
4. Protection of your sales area, ideas of design and all your private information.
|
|
