Fluke 435-II 3-Phase Power Quality and Energy Analyzers quickly troubleshoot

Fluke 435-II 3-Phase Power Quality and Energy Analyzers quickly troubleshoot

  • Fluke 435-II 3-Phase Power Quality and Energy Analyzers quickly troubleshoot
  • Fluke 435-II 3-Phase Power Quality and Energy Analyzers quickly troubleshoot
  • Fluke 435-II 3-Phase Power Quality and Energy Analyzers quickly troubleshoot
Fluke 435-II 3-Phase Power Quality and Energy Analyzers quickly troubleshoot
Product Details:
Place of Origin: US
Brand Name: Fluke
Model Number: 435-II
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Payment Terms: T/T
Supply Ability: in stock
Contact Now
Detailed Product Description
Product Name: Power Quality And Energy Analyzers Condition: New
SD Card: 8 GB Signaling Frequency: 60 Hz To 3000 Hz
Standard Compliance: IEC 61000-4-30 Class A Functions: Tested, In Full Working Conditions

Fluke 435-II 3-Phase Power Quality and Energy Analyzers



Description of Fluke 435-II Power Quality and Energy Analyzers

The 435-II Power Quality and Energy Analyzer are designed to help you minimize downtime, quickly troubleshoot power quality issues and easily discover the costs of wasted energy. Downtime is expensive and getting the data you need to solve to critical power quality problems quickly is key. The 435-II Analyzer’s measurement process and data output have been optimized to help you access the most critical information easily.



Multiple parameters are measured simultaneously and displayed in formats that quickly describe overall power quality health. The detailed information helps you make better maintenance decisions—whether you’re trying to reduce energy waste, find the source of power quality issues or see how motor startups are affecting your electrical system. Data can be accessed as simple digital values, trend graphs (for fast insight into changes over time), waveforms, or phasor diagrams. The data can also be analyzed and organized into tabular formats. Detailed event data allows you to see the magnitude, duration and time stamping of anomalies enabling you to rapidly correlate the problems you are experiencing in your facility.



The 435-II Power Quality and Energy Analyzer utilize an integrated Power Quality Health summary that gives you an at-a-glance view of a complete range of power quality issues in real time. With a simple graphical presentation, complete with tolerance limits, you can quickly discover which power quality problems may be present on your electrical system. If you don’t know where to start or what problems might exist, the advanced Power Quality Health summary simplifies the task and serves as a comprehensive starting point for further troubleshooting.



General Specifications of Fluke 435-II 3-Phase Power Quality and Energy Analyzers

Case: Design Rugged, shock proof with integrated protective holster Drip and dust proof IP51 according to IEC60529 when used in tilt stand position Shock and vibration Shock 30 g, vibration: 3 g sinusoid, random 0.03 g 2 /Hz according to MIL-PRF-28800F Class 2

Dispaly: Brightness: 200 cd/m 2 typ. using power adapter, 90 cd/m 2 typical using battery power Size: 127 x 88 mm (153 mm/6.0 in diagonal) LCD Resolution: 320 x 240 pixels Contrast and brightness: user-adjustable, temperature compensated

Memory:8GB SD card (SDHC compliant, FAT32 formatted), up to 32GB optionally. Screen save and multiple data memories for storing data including recordings (dependent on memory size).

Real-Time Clock: Time and date stamp for Trend mode, Transient display, System Monitor and event capture



Wrapped in a lightweight, rugged package, the Fluke 435-II Power Quality and Energy Analyzer are the ideal portable power quality instruments.

  • Quickly see how much money you’re losing due to energy waste in terms of real dollars
  • Highest safety rating in the industry: 600 V CAT IV/1000 V CAT III rated for use at the service entrance
  • Measure all three phases and neutral with the included flexible current probes
  • Easily see how motor startups are affecting electrical system performance
  • Get at-a-glance power quality health data in real-time so you can make better maintenance decisions
  • Fluke Connect® compatible* – view data locally on the instrument, via Fluke Connect mobile app and PowerLog 430-II desktop software



Models: Fluke 435-II Power Quality and Energy Analyzers



Fluke 435-II
Fluke 435 Series II Power Quality and Energy Analyzer with current probes

Includes:

  • BC430 Power Adapter
  • International Plug Adapter Set
  • BP290 (Single Capacity Li-ion Battery) 28 Wh (8 hours or more)
  • TLS430 Test Lead and Alligator Clip Set
  • WC100 Color Coding Clips and Regional Decals
  • i430-Flexi-TF-II, 24 inch (61 cm) Length, 4 Flexible Current Probes
  • 8GB SD card
  • PowerLog on CD (includes operator manuals in PDF format)
  • USB Cable A - Mini B
  • Soft Carrying Bag

Fluke 435-II 3-Phase Power Quality and Energy Analyzers quickly troubleshoot 0







FAQ:

1.Can you ship order to Canada or Australia ?
Yes,we can .We send orders worldwide .
2. What delivery method do you use ? and delivery time ?
We can ship by EMS,DHL,FedEx,UPS,TNT with tracking number. Usual delivery time is 4-7 workdays.
3. What is your payment term?
100% T/T payment before shipment.
4. How can I ask any other question ?
You can contact us online or leave us messages below .



Fluke 435-II 3-Phase Power Quality and Energy Analyzers quickly troubleshoot 1Fluke 435-II 3-Phase Power Quality and Energy Analyzers quickly troubleshoot 2



Fluke 435-II 3-Phase Power Quality and Energy Analyzers quickly troubleshoot 3
