8.5 Digits Fluke 8508A Reference Multimeter Superior Accuracy ISO 17025 Standard

8.5 Digits Fluke 8508A Reference Multimeter Superior Accuracy ISO 17025 Standard

  • 8.5 Digits Fluke 8508A Reference Multimeter Superior Accuracy ISO 17025 Standard
  • 8.5 Digits Fluke 8508A Reference Multimeter Superior Accuracy ISO 17025 Standard
  • 8.5 Digits Fluke 8508A Reference Multimeter Superior Accuracy ISO 17025 Standard
  • 8.5 Digits Fluke 8508A Reference Multimeter Superior Accuracy ISO 17025 Standard
8.5 Digits Fluke 8508A Reference Multimeter Superior Accuracy ISO 17025 Standard
Product Details:
Place of Origin: USA
Brand Name: Fluke
Certification: ISO:17025 Accredited Calibration
Model Number: 8508A
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Payment Terms: T/T
Supply Ability: in stock
Contact Now
Detailed Product Description
Product Name: Digit Reference Multimeter Digit Resolution: 8.5
Condition: Pre-Owned Functions: Tested, In Full Working Conditions
High Light:

8.5 Digits Fluke 8508A Reference Multimeter

,

Superior Accuracy Fluke 8508A Reference Multimeter

,

ISO 17025 Fluke 8508A Multimeter



Fluke 8508A Reference Multimeter 8.5 Digits



Description of Fluke 8508A



The Fluke 8508A is an 8.5-digit resolution instrument designed specifically for metrologists. With superior accuracy and stability over a wide range of measurements the 8508A is designed to serve as a versatile precision measurement tool for calibration laboratories that must meet increasingly stringent measurement uncertainty analysis requirements demanded by ISO 17025, as well as the need for increased productivity.



Model Name Description
8508A Reference Multimeter
8508A/01 Reference Multimeter with front and rear input binding posts
Summary Specifications
Voltage DC
Range: 0 to ± 1050 V
Best 1 Year Absolute Specification: ± 3 ppm of reading
Voltage AC
Range: 2 mV to 1050 V, 1 Hz to 1 MHz
Best 1 Year Absolute Specification: ± 65 ppm of reading
Current DC
Range: 0 to ± 20 A
Best 1 Year Absolute Specification: ± 12 ppm of reading
Current AC
Range: 2 µA to 20 A, 1 Hz to 100 kHz
Best 1 Year Absolute Specification: ± 250 ppm of reading
Resistance
Range: 0 to 20 GΩ
Best 1 Year Absolute Specification: ± 7.5 ppm of reading
Temperature
Range: Range: -200 °C to 660 °C
Best 1 Year Absolute Specification: ± 2.5 m °C*
Calibration Documentation
17025 accredited report of calibration included

*Typical equivalent measurement uncertainty for 100 Ω PRT/SPRT probe at 0 °C

Accessories common to all models:

Accessory Description
8508A/CASE Transit Case
8508A-7000K Calibration Kit 8508A Calibration-support-kit for use with characterized 5720A Multifunction Calibrator
8508A-LEAD Comprehensive Measurement Lead Kit
8508A-PRT Platinum Resistance Thermometer
8508A-SPRT Standard Platinum Resistance Thermometer
Y8508 Rack Mount Kit
Y8508S Rack Mount Kit Slides
Priority Gold Instrument CarePlan Fluke Calibration Priority Gold Instrument CarePlans are available for most calibration products. Please contact your local Fluke Calibration sales representative for details or to request a quote.
Silver CarePlan Fluke Calibration Silver CarePlans are available for most calibration products.
FAQ:

1.Can you ship order to Canada or Australia ?
Yes,we can .We send orders worldwide .
2. What delivery method do you use ? and delivery time ?
We can ship by EMS,DHL,FedEx,UPS,TNT with tracking number. Usual delivery time is 4-7 workdays.
3. What is your payment term?
100% T/T payment before shipment.
4. How can I ask any other question ?
You can contact us online or leave us messages below .
