The Keysight M8195A is a high-speed AWG with up to 65 GSa/s sample rate and 25 GHz bandwidth on up to 4 channels per module. The Keysight M8195A arbitrary waveform generator (AWG) provides up to 65 GSa/s, 25 GHz bandwidth, 8 bits vertical resolution, and up to 4 channels in a 1-slot AXIe module - simultaneously. As devices and interfaces become faster and more complex, the M8195A AWG gives you the versatility to create the signals you need for digital applications, advanced research, wideband radar, satcom, and optical communications. Advanced 3-level sequencing allows even longer signal scenarios. An external dynamic control is available for the case of a M8197A module synchronizing several M8195A modules. The M8195A AWG features a trigger input with a delay accuracy of ±20 ps in conjunction with a M8197A multi-channel synchronization module. In conjunction with the N5990A software option 151 & 153 the M8195A provides a sink test solution for HDMI and MHL. The M8195A AWG can also be controlled by the M8070A Bit Error Ratio Test system software with the M8085A software plug-in to create MIPI C-PHY™ and D-PHY™ standard conformant test signals. The M8195A AWG combined with the 81195A optical modulation generator software introduces an innovative real-time approach which speeds up your test by a factor of up to 100. It allows signal and impairment generation in real time. FIR filters and other DSP functions are used for pulse-shaping and changing optical stress conditions such as polarization mode dispersion (PMD) or phase noise. Go where you have never been able to test before: with real-time mode, sequencing and deep memory - explore your possibilities. Additional Information: The M8195A is also available in a system bundle M8195S, which is dynamically configured depending on the required number of channels. In addition to the module itself, an AXIe chassis, embedded controller or external PC connectivity will automatically be added and the system is shipped pre-configured.
Highlights
As devices and interfaces become faster and more complex, the Keysight M8195A arbitrary waveform generator (AWG) provides the versatility needed to create signals for digital applications, optical and electrical communication, advanced research, wideband radar, and satcom.
In addition to 25 GHz bandwidth, 8-bit vertical resolution, and up to 4 channels in a 1-slot AXIe module, the M8195A offers real-time signal and impairment generation, as well as advanced 3-level sequencing for even longer signal scenarios. Enhance your test setup with real-time mode, built-in frequency and phase response calibration, sequencing, and deep memory.
generate two independent I/Q baseband signals (dual polarization = 4 channels) at up to 32 GBaud and beyond
produce NRZ, PAM4, PAM8, D-M-T, etc. signals at up to 32 GBaud
support protocols such as HDMI™, C-PHY™ and D-PHY™
embed / de-embed channels, add jitter, ISI, noise, and other distortions
supply any mathematically defined arbitrary waveforms, ultra-short yet precise pulses, and extremely wideband chirps
enable up to 1 Vpp(se) or 2 Vpp(diff) output amplitude
provide wideband RF signals with an instantaneous bandwidth of DC to 25 GHz for aerospace and defense, or communication applications
extend memory capabilities with 16 GSa to generate PRBS7, PRBS10, PRBS11, PRBS15 up to PRBS31
List of options
001 | Arbitrary Waveform Generator, 1 Channel, 65 GSa/s |
002 | Arbitrary Waveform Generator, 2 Channels, 65 GSa/s |
004 | Arbitrary Waveform Generator, 4 Channels, 65 GSa/s |
16G | Upgrade to 16 GSa Memory |
1A7 | Calibration + Uncertainties + Guardbanding (Not Accredited) |
1NP | DUT Control Interface, Network/Floating, Perpetual License |
1TP | DUT Control Interface, Transportable, Perpetual License |
810 | Matched Cable Pair for M8195A AWG, 2.92 mm |
BU1 | Bundle consisting of one M9505A 5-slot AXIe Chassis with USB Option and one M9537A AXIe Embedded PC Controller |
BU2 | Bundle consisting of one M9502A 2-slot AXIe Chassis with USB Option |
BU3 | Bundle consisting of one M9502A 2-slot AXIe Chassis with USB Option and one M9537A AXIe Embedded PC Controller |
FSW | Fast Switching |
M9048A | PCIe Desktop Adapter: Gen 2, x8, clock isolation |
N6171A | MATLAB Software |
N6171A-M01 | MATLAB-Basic Package, individual license - node-locked |
N6171A-M02 | MATLAB-Standard Package, individual license - node-locked |
N6171A-M03 | MATLAB-Advanced Package, individual license - node-locked |
ONP | System Software for M8000 Series of BER Test Solutions, Network/Floating, Perpetual License |
OSP | Optical Signal Properties, transportable, perpetual License |
OTP | System Software for M8000 Series of BER Test Solutions, Transportable, Perpetual License |
RSP | Real-time Signal Processing, transportable, perpetual License |
SCD | Standard Calibration Document |
SEQ | Sequencer |
U12 | Arbitrary Waveform Generator Upgrade of M8195A-R12 or -E52 to Revision 2 |
U14 | Arbitrary Waveform Generator Upgrade of M8195A-R14 or -E54 to Revision 2 |
Y1202A | PCIe cable: x8, 2.0m |
Z54 | Calibration Certificate for Z540 |
