Agilent Keysight E5052A Signal Source Analyzer 10 MHz - 110 GHz Phase Noise Measurement

Agilent Keysight E5052A Signal Source Analyzer 10 MHz - 110 GHz Phase Noise Measurement

  • Agilent Keysight E5052A Signal Source Analyzer 10 MHz - 110 GHz Phase Noise Measurement
  • Agilent Keysight E5052A Signal Source Analyzer 10 MHz - 110 GHz Phase Noise Measurement
  • Agilent Keysight E5052A Signal Source Analyzer 10 MHz - 110 GHz Phase Noise Measurement
  • Agilent Keysight E5052A Signal Source Analyzer 10 MHz - 110 GHz Phase Noise Measurement
  • Agilent Keysight E5052A Signal Source Analyzer 10 MHz - 110 GHz Phase Noise Measurement
Agilent Keysight E5052A Signal Source Analyzer 10 MHz - 110 GHz Phase Noise Measurement
Product Details:
Place of Origin: Malaysia
Brand Name: Keysight Agilent
Model Number: E5052A
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Carton
Delivery Time: 1~3 working days
Payment Terms: T/T, L/C, Paypal, Western Union, MoneyGram
Supply Ability: In Stock
Contact Now
Detailed Product Description
Form Factor: Benchtop,Plug-In ( /1EE ),Rackmount ( /1CM /1CP ) Frequency: 7 26.5 Or 110 GHz
Condition: Pre-owned, In Full Working Conditions Model No.: E5052A
High Light:

Signal Source Analyzer

,

110 GHz Signal Source Analyzer

,

Phase Noise Measurement Signal Source Analyzer

Agilent Keysight E5052A Signal Source Analyzer 10 MHz to 7 26.5 or 110 GHz Signal Analyzer



Features:

  • 10 MHz to 110 GHz frequency range (View frequency selection)
  • Versatile measurement functions in a single instrument
  • Phase noise measurement
  • Transient measurement (frequency/phase/power over time)
  • Frequency, power, and DC current measurement (VCO characterization)
  • Spectrum monitoring
  • View SSA options and accessories

Phase Noise Measurement Table 1-1. Phase noise measurement Description Specifications Frequency range 10 MHz to 7 GHz Frequency bands 10 M to 41 MHz 39 M to 101 MHz 99 M to 1.5 GHz 300 M to 7 GHz Offset frequency range Carrier > 400 MHz 1 Hz to 40 MHz (standard) 10 Hz to 40 MHz (Option E5052A-011) 39 MHz ≤ Carrier ≤ 99 MHz 1 Hz to 20 MHz (standard) 10 Hz to 20 MHz (Option E5052A-011) 10 MHz ≤ Carrier ≤ 39 MHz 1 Hz to 5 MHz (standard) 10 Hz to 5 MHz (Option E5052A-011) Enhanced phase noise sensitivity1 Cross-correlation method (standard) Number of correlation: 1 to 10,000 Frequency tracking range 0.4% of carrier frequency IF gain 0, 10, 20, 30, 40, 50 dB (standard) 0, 10, 20 dB (E5053A-011) Input level 10 to 30 MHz –15 to +20 dBm 30 MHz to 7 GHz –20 to +20 dBm Built-in LO phase noise optimization < 150 kHz (optimized for close-in phase noise) > 150 kHz (optimized for far-out phase noise) See Figure 1-2 Accuracy 1 to 100 Hz offset < ± 4 dB (typical) 100 to 1 kHz offset < ± 4 dB (typical) 1 k to 1 MHz offset < ± 2 dB (typical) 1 M to 40 MHz offset < ± 3 dB (typical) SSB phase noise sensitivity See Table 1-2 through Table 1-4, Figure 1-1 through Figure 1-3 Spurious level 65 dBc (typical) > 1 kHz offset Measurement time See Table 1-5


List of Options
011 Delete Functions
1A7 ISO 17025 Compliant Calibration
1CM Rackmount Kit
1CN Handle Kit
1CP Rackmount and Handle Kit
810 Add keyboard
820 Add mouse
ABA U.S. Quick Users Guide (English localization)
ABJ Japan Quick Users Guide (Japanese localization)
E5001A-1FP PRECISION CLOCK JITTER ANALYSIS
H01 SSA-BBM Enhanced measurement capability
R-51B-001-3C 1 year Return-to-Agilent warranty extended to 3 years
RMKT Agilent Refurbished Product (Do Not Use - Certiprime Option)
SSA-J precision clock jitter analysis software
