Agilent E3632A DC Power Supply Dual Range Output Programmable Used Test Instruments

Brand Name: Keysight (Agilent)
Model Number: E3632A
MOQ: 1 set
Price: Negotiation
Delivery Time: 1~3 Working Days
Payment Terms: T/T, Western Union, MoneyGram
Detail Information
Place of Origin:
Malaysia
Product Name:
DC Power Supply
Single Output,:
120-200 W
Dual Range Outputs:
E3632A-E3634A
Power:
120 W
Voltage:
15 V 30 V
Connectivity:
GPIB,RS232,USB ( /PCUSB )
Condition:
Pre-Owned
Functions:
Tested, In Full Working Conditions
Form Factor:
Rackmount ( /1CM /1CP ),Benchtop
Current:
4 A,7 A
Packaging Details:
Carton
Supply Ability:
in stock
Product Description

Agilent E3632A DC Power Supply Dual Range Output Programmable Used Test Instruments



Description of  Keysight Agilent E3632A



Agilent basic DC power supplies single output, 120-200 W, GPIB, E3632A-E3634A provide dual range outputs; small, compact size for bench use; low output ripple and noise; as well as built-in measurements and basic programmable features with GPIB and RS232 interface. The Agilent 120W, GPIB, single output E3632A is a high performance supply optimized for manual and basic automated testing; and, with a combination of benchtop capabilities and system features, it is designed to help improve measurement quality and reduce test time.



Output Ratings

  • Range 1: 0 to 15 V, 7 A
  • Range 2: 0 to 30 V, 4 A

Programming Accuracy at 25°C ±5°C

  • Voltage: 0.05% + 10 mV
  • Current: 0.2% +10 mA

Ripple & Noise (20 Hz to 20 MHz)

  • Normal-mode voltage: <350 µVrms/2 mVpp
  • Normal-mode current: <2 mA rms
  • Common-mode current: <1.5 µA rms

Readback Accuracy at 25°C ±5°C

  • Voltage: 0.05% + 5 mV
  • Current: 0.15% + 5 mA



List of Options



000



110/220v Single-phase w/CT: 4-



0E3



AC 230V single-phase 3-wire. 230 VAC +/- 23V operation, 47 to 63 Hz



0E9



AC 100V single-phase 3-wire. 100 VAC +/- 10V operation, 47 to 63 Hz



0EM



AC 115V single-phase 3-wire. 115 VAC +/- 11V operation, 47 to 63 Hz



0L2



English language operation manual, printed



1CM



Rackmount Kit - mounts one with blank filler panel included



1CN



Rackmount Kit - mounts two products side-by-side



1CP



Rack Mount Kit - mounts 3U instrument to the front of System II rack



910



Additional operating and service manual



E3600A-100



Test Lead Kit, Banana plug to SMT grabber



PCUSB



82357A USB/GBIP Interface



R-50C-011-3



Agilent Calibration - 3 years



R-50C-011-5



Agilent Calibration - 5 years



R-50C-021-3



ANSI Z540-1-1994 Calibration - 3 years



R-50C-021-5



ANSI Z540-1-1994 Calibration - 5 years



R-51B-001-C



Return to Agilent Warranty - 1 year



UK6



Commercial calibration certificate with test data included



Our service:

One-stop service from manufacture to shipping.
1. Your inquiry related to our products or prices will be replied in 24hours.
2. Well-trained and experienced staffs to answer all your enquires influent English.
3. Distributor ship is offered for your unique desigh and some our current models.
4. Protection of your sales area, ideas of design and all your private information.


FAQ:

1.Can you ship order to Canada or Australia ?

Yes,we can .We send orders worldwide .

2. What delivery method do you use ? and delivery time ?

We can ship by EMS,DHL,FedEx,UPS,TNT with tracking number. Usual delivery time is 4-7 workdays.

3. What is your payment term?

100% T/T payment before shipment.

4. How can I ask any other question ?

You can contact us online or leave us messages below.
