Portable Agilent N9913A FieldFox Handheld RF Analyzer 4 GHz Keysight Spectrum Analyzer

Portable Agilent N9913A FieldFox Handheld RF Analyzer 4 GHz Keysight Spectrum Analyzer

  • Portable Agilent N9913A FieldFox Handheld RF Analyzer 4 GHz Keysight Spectrum Analyzer
  • Portable Agilent N9913A FieldFox Handheld RF Analyzer 4 GHz Keysight Spectrum Analyzer
  • Portable Agilent N9913A FieldFox Handheld RF Analyzer 4 GHz Keysight Spectrum Analyzer
  • Portable Agilent N9913A FieldFox Handheld RF Analyzer 4 GHz Keysight Spectrum Analyzer
  • Portable Agilent N9913A FieldFox Handheld RF Analyzer 4 GHz Keysight Spectrum Analyzer
Portable Agilent N9913A FieldFox Handheld RF Analyzer 4 GHz Keysight Spectrum Analyzer
Product Details:
Place of Origin: Malaysia
Brand Name: Keysight Agilent
Model Number: N9913A
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Payment Terms: T/T
Supply Ability: in stock
Contact Now
Detailed Product Description
Product Name: Handheld RF Analyzer Frequency: 30 KHz To 4 GHz
Instrument Type: Cable And Antenna Analyzer (CAT) Vector Network Analyzer (VNA) Condition: Pre-Owned
Functions: Tested, In Full Working Conditions Portable: Yes
High Light:

Portable Keysight Spectrum Analyzer

,

FieldFox Handheld RF Analyzer

,

4 GHz Keysight Spectrum Analyzer

Portable Agilent N9913A FieldFox Handheld RF Analyzer 4 GHz Keysight Spectrum Analyzer



Description of  Keysight Agilent N9913A



Cable and antenna analyzer (CAT), vector network analyzer (VNA)

  • 30 kHz to 4 GHz
  • CAT: Distance-to-fault, return loss, cable loss
  • VNA dynamic range: 100 dB to 4 GHz
  • VNA: S11, S21, S22, S12, magnitude and phase

Spectrum analyzer

  • 5 kHz to 4 GHz
  • ± 0.5 dB amplitude accuracy, full band, over full temperature range of -10 to +55 °C (14 to 131 °F)
  • Spur-free dynamic range: ≥ 105 dB
  • Full-band tracking generator

Independent source, vector voltmeter (VVM) and power measurements

  • RF source: 30 kHz to 4 GHz, CW, CW coupled, and tracking
  • VVM: 30 kHz to 4 GHz, compare phase and electrical length
  • Average and peak power measurements with USB sensor
  • Built-in power meter: 5 kHz to 4 GHz

FieldFox instrument attributes

  • New: Remote control via iPad or iPhone
  • Standard 3-year warranty
  • Battery life: 3.5-hours; weight: 3.0 kg or 6.6 lbs
  • Operating temperature: -10 to +55 °C (14 to 131 °F)

Keysight's FieldFox portable analyzers are equipped to handle your toughest working environments during routine maintenance, in-depth troubleshooting, and anything in between. Choose the Keysight FieldFox configuration that best meets your needs.

  • Standard model includes cable and antenna analyzer (CAT).
  • Expand capabilities with optional VNA, spectrum analyzer, built-in power meter, vector voltmeter, and more.
  • Save time by measuring DTF and TDR in the same sweep.
  • Measure all four S-parameters simultaneously.
  • Make accurate spectrum analyzer measurements (± 0.5 dB) without warm-up.
  • Calibrate easily with QuickCal.
  • Use the industry's lightest all-in-one analyzer at only 3.0 kg (6.6 lb).

Applications

  • Satellite communications, microwave backhaul
  • Military communications, radar systems
  • Active and passive device test

Accuracy

  • Get precise measurements that agree with benchtop results
  • QuickCal – Built-in calibration – no cal kit required
  • CalReady – Immediate distance-to-fault and S-parameter measurements at test port
  • InstAlign – Unprecedented absolute amplitude accuracy across the full band, no warm-up required
List of Options
010 Vector network analyzer time domain
030 Remote control capability
112 QuickCal
210 Vector network analyzer transmission/reflection
211 Vector network analyzer full 2-port S-parameters
215 TDR Cable Measurements
233 Spectrum Analyzer
233 Spectrum analyzer
235 Pre-amplifier
236 Interference analyzer and spectrogram
238 Spectrum analyzer time gating
302 USB power sensor support
307 GPS receiver
308 Vector voltmeter
309 DC bias variable-voltage source
310 Built-in power meter

FAQ:

1.Can you ship order to Canada or Australia ?

    Yes,we can .We send orders worldwide .

2. What delivery method do you use ? and delivery time ?

    We can ship by EMS,DHL,FedEx,UPS,TNT with tracking number. Usual delivery time is 4-7 workdays.

3. What is your payment term?

    100% T/T payment before shipment.

4. How can I ask any other question ?

    You can contact us online or leave us messages below .
