Portable FSU26 RF Spectrum Analyzer 20Hz-26.5GHz Pre-Owned Rohde And Schwarz

Name: Portable FSU26 RF Spectrum Analyzer 20Hz-26.5GHz Pre-Owned Rohde And Schwarz
Brand: Shenzhen Meigaolan Electronic Instrument Co. Ltd
SKU: FSU26
Availability: InStock

Brand Name:	Rohde and Schwarz
Model Number:	FSU26
MOQ:	1 set
Price:	Negotiation
Payment Terms:	T/T

Detail Information

Product Description

Ratings & Reviews

Detail Information

Place of Origin:

Czech Republic

Certification:

FCC

Product Name:

Spectrum Analyzer

Frequency:

20 Hz To 26.5 GHz

Form Factor:

Benchtop Portable

Average Noise Level:

-155 DBm

Condition:

Pre-Owned

Functions:

Tested, In Full Working Conditions

Packaging Details:

Carton

Supply Ability:

in stock

Highlight:

Portable RF Spectrum Analyzer

FSU26 RF Spectrum Analyzer

Durable FSU26 Spectrum Analyzer

Product Description

Portable FSU26 RF Spectrum Analyzer 20Hz-26.5GHz Rohde And Schwarz

Rohde and Schwarz FSU26 RF Spectrum Analyzer

The R&S FSU spectrum analyzers are performance leaders in dynamic range, phase noise, level accuracy and resolution bandwidth—all essential factors for designing, characterizing, and manufacturing next-generation wireless elements.

Key Features

Frequency Range: 20 Hz to 26.5 GHz
DANL: -158dBm (1 Hz RBW)
Phase Noise (Typ.): -133 dBc @ 10 KHz offset (1 Hz RBW)
TOI (Typ.): +25 dBm
Resolution Bandwidth: 1 Hz to 50 MHz
DANL with Preamplifier option B24: typ. -168 dBm (1Hz RBW) @ 20 GHz
Fast ACP in time domain
Up to 70 measurements per second (including trace transfer via GPIB)
Measurement routines for TOI, MC ACP(R), OBW, CCDF, APD, etc. as standard
Application firmware available for GSM/EDGE, Bluetooth, WCDMA/HSPDA/TD-SCDMA, CDMA-2000/1xEV-DV/1xEV-D0, etc.

Specifications & Attributes

Form Factor	Rackmount (/ZZA-411)
Application Software	Bluetooth (/K8), CDMA2000 (/K82), CDMAONE (/K82), GSM with Edge (/K5), HSDPA (/K74), Noise Figure (/K3), Phase Noise (/K4), TD-SCDMA (/K77)
Average Noise Level	-158 dBm
Frequency	10 MHz (/B27 /B4), 640 MHz (/B5), 100 KHz - 3.6 GHz (/B9), 10 MHz - 3.6 GHz (/B25), 20 Hz - 26.5 GHz

Available Options

Option Code	Description
1R	Rack mount Adapter ZZA-94
B04	OCXO 10MHZ FOR FSU AGING/YEAR
B10	External generator control for FSP, FSU, FSG, FSQ, ESU, ESCI, ESPI and for retrofit of
B12	Output attenuator for tracking generator for FSU, FSQ
B16	LAN interface
B18	Removable Hard Disk (not retrofittable)
B19	B18,vaSecond Hard Disk for FSU-B18 (for FSU-riant 1303.0400.02)
B20	Extended environment specification. Random vibr. 1.9G RMS, 0-55°C (not retrofittable)
B21	LO/ZF connections for external mixers (for FSQ26, FSQ40,FSU26, FSU43, FSU46, FSU50)
B23	Preamplifier 20 dB to FSU26, 3.6 - 26.5 GHz not retrofittable
B24	Preamplifier 30dB, 100 kHz to 50GHz (for FSMR26/43/50, FSQ26/40, FSU26/43/46/50;
B25	Electronic attenuator 0 to 30 dB, Preamplifier 20 dB, 10MHz - 3.6 GHz for FSU, FSQ
B27	FM output, 10 MHz bandwidth
B28	Trigger port for FSP,FSQ,FSU; for indication of trigger conditions
B4	OCXO 10 MHz aging/year: 0.35*10E-7 for FSU, FSQ, FSMR
B5	Output for low phase noise 640MHz reference signal for FSU3, FSU8, FSQ3 und FSQ8
B73	Vector signal analysis for FSU demodulation bandwidth 8 MHz (FSU), broadband demodulation hardware included
B87	Extended linearity specification for specific channel filters
B88	RF hardware option 1 FSU26
B9	Tracking generator for FSU and FSQ, 100 kHz - 3.6 GHz

Frequently Asked Questions

1. Can you ship orders to Canada or Australia?

Yes, we can. We send orders worldwide.

2. What delivery method do you use and what is the delivery time?

We can ship by EMS, DHL, FedEx, UPS, TNT with tracking number. Usual delivery time is 4-7 workdays.

3. What is your payment term?

100% T/T payment before shipment.

4. How can I ask any other questions?

You can contact us online or leave us messages below.

Product Images
