Used USB Sensor Keysight Agilent U2002H USB Power Sensor 50 MHz to 24 GHz

Used USB Sensor Keysight Agilent U2002H USB Power Sensor 50 MHz to 24 GHz

  • Used USB Sensor Keysight Agilent U2002H USB Power Sensor 50 MHz to 24 GHz
  • Used USB Sensor Keysight Agilent U2002H USB Power Sensor 50 MHz to 24 GHz
  • Used USB Sensor Keysight Agilent U2002H USB Power Sensor 50 MHz to 24 GHz
Used USB Sensor Keysight Agilent U2002H USB Power Sensor 50 MHz to 24 GHz
Product Details:
Place of Origin: USA
Brand Name: Keysight (Agilent)
Model Number: U2002H
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: Negotiation
Packaging Details: Carton
Delivery Time: 1~3 Working Days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: In Stock
Contact Now
Detailed Product Description
Product Name: USB Power Sensor Frequency Range: 50 MHz To 24 GHz
Power Measurements: -50dBm To +30dBm Condition: Pre-Owned
Functions: Tested, In Full Working Conditions Form Factor: Plug-In

Used USB Sensor Keysight Agilent U2002H USB Power Sensor 50 MHz to 24 GHz

Description of U2002H USB Power Sensor



Agilent U2000 Series USB power sensors make setup and measurement fast without the need of a power meter, just plug the USB sensor cable to the PC, you can control the USB power sensor with the FREE Power Panel N1918A software.

Internal triggering enables triggering based on the burst signal envelope, eliminating the need for an external triggering signal.Trace display provides a graphical view of the signal envelope to assist in gate placement and trigger level setup. All U2000 sensors, except for the U2004A, feature these new capabilities. If you are a current user of the U2000 sensors, simply download the firmware upgrade for free.


Instruments Compatibility:
Now it is fully firmware compatible with Agilent selected instrument, just upgrade your instrument to the compatible firmware version to start using the U2000 series USB power sensor on your instrument. Note: to use the U2000 series USB power sensor, you DO NOT need to install N1918A Power Panel onto the instrument, the instrument just requires firmware upgrade to the compatible version.



Features

  • Frequency range of 50 MHz to 24 GHz
  • Wide dynamic range (-50 dBm to +30 dBm)
  • Internal zeroing while connected to the DUT
  • High measurement speed of up to 250readings/second
  • Support internal and external trigger measurements
  • Display power measurements on a PC without the need of power meter
  • Compatible with other Agilent instruments
  • Internal triggering and trace display capability
List of Options



1A7



Certificate of compliance calibration - ISO 17025 with test data, printed



A6J



Certificate of compliance calibration - ANSI Z540 with test data, printed



N1918A



Power Analysis Manager -N1918A



N1918A-100



N1918A Power Analyzer (with PC License)



N1918A-200



N1918A Power Analyzer (with USB License Key)



R-50C-011-3



Agilent Calibration - 3 years



R-50C-011-5



Agilent Calibration - 5 years



R-50C-016-3



ISO 17025 Compliant Calibration - 3 years



R-50C-016-5



ISO 17025 Compliant Calibration - 5 years



R-50C-021-3



ANSI Z540-1-1994 Calibration - 3 years



R-50C-021-5



ANSI Z540-1-1994 Calibration - 5 years



R-51B-001-3C



Return to Agilent Warranty - 3 years



R-51B-001-5C



Return to Agilent Warranty - 5 years



R-51B-001-C



Return to Agilent Warranty - 1 year



U2000A-202



Soft Carrying Case



U2000A-203



Holster



U2000A-204



Soft Carrying Pouch



U2000A-301



Power sensor cable; 5-ft (1.5m)



U2000A-302



Power sensor cable; 10-ft (3m)



U2000A-303



Power sensor cable; 16.4-ft (5m)



U2000B-201



Transit Case



U2031A



Power sensor cable; 5-ft (1.5m)



U2031B



Power sensor cable; 10-ft (3m)



U2031C



Power sensor cable; 16.4-ft (5m)



U2032A



Trigger Cable BNC Male to SMB female 50ohm, 1.5meter length
