Keysight Agilent N9320B RF Spectrum Analyzer BSA

Name: Keysight Agilent N9320B RF Spectrum Analyzer BSA
Brand: Agilent
SKU: N9320B
Rating: 4.6 (105 reviews)

Product Details:

Place of Origin:	Malaysia
Brand Name:	Agilent
Model Number:	N9320B

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiation
Payment Terms:	T/T
Supply Ability:	in stock

Contact Now

Detailed Product Description

Product Name:	RF Spectrum Analyzer	Frequency:	9 KHz To 3 GHz
Form Factor:	Benchtop	Average Noise Level:	-148 DBm - -130 DBm
Condition:	Pre-Owned	Functions:	Tested, In Full Working Conditions

Keysight Agilent N9320B RF Spectrum Analyzer BSA

Description of Keysight Agilent N9320B

Regardless of whether your application is electronics’ manufacture, bench repair, RF education or R&D projects, you need a spectrum analyzer that is equipped with the essential functionality, required performance at an affordable price. The N9320B is designed to be the right answer for you.

Enhanced Power Measurement and Easy Automated Test Programming Features

The accuracy of frequency selective power measurements when characterizing your products is very important. With a newly featured digital IF, the N9320B provides measurement accuracy and speed you need to accomplish tasks easily
Power meter functionality is a standard feature built-in with Agilent U2000 series power sensor support for highly accurate RF and MW power measurements
Direct access to perform one-button power measurement functions offer channel power, ACP, OBW, SEM and TOI measurements
For automated test programming, the N9320B provides industry standard SCPI language support and connectivity choices with USB and LAN. SCPI code compatible with Agilent ESA-L Series enables easy migration from ESA-L to the N9320B

Consolidated Solution for RF Teaching Lab

One of the best ways to improve students’ learning efficiency for RF related curriculums is to combine lectures with hands-on labs. The N9320B is an excellent price-performance fit for educational purposes. Whether you wish to combine the N9320B analyzer with the Agilent N9310A RF signal generator for basic RF concept labs, or enhance your RF circuit labs with the N9320B and its optional RF training kit (option code: N9320B-TR1), you will find adopting Agilent’s RF education solution efficient and effective. Learn more from RF Lab Station.

Professional Performance for Spectrum Analysis from 9 kHz to 3 GHz

Minimum non-zero span sweep time: < 10 ms
Resolving power RBW: 10 Hz to 1 MHz
Sensitivity DANL: -130 dBm, -148 dBm with preamp on
Overall amplitude accuracy: ±1.5 dB, typical ±0.5 dB

Robust Measurement Features for Characterizing Your Product Easily

Built-in power measurements: channel power, OBW, ACP, SEM and TOI
Built-in power meter function with Agilent U2000 series power sensor support
Optional tracking generator and preamplifier
Optional AM/FM demodulation capability

Accessibility and Ease-of-Use at Your Finger Tips

Customized power-on or “preset” enabled setups
Standard USB and LAN interface
Multiple language user interface
Free remote control PC software

List of Options

1CM	Rack mount kit for N9320B spectrum analyzer
1HB	Handle and Bumper
1TC	Hard Transit Case
ABA	English user's guide, printed
AMA	AM/FM demodulation metrics
DMA	ASK/FSK demodulation metrics
EMF	EMC Filter
G01	GPIB Interface
PA3	Preamplifier, 3 GHz
PLG	Continental European power cord - ONLY FOR EU DISTR W MULT PWR CORD STANDARDS
R-50C-011-3	Agilent Calibration - 3 years
R-50C-011-5	Agilent Calibration - 5 years
R-50C-021-3	ANSI Z540-1-1994 Calibration - 3 years
R-50C-021-5	ANSI Z540-1-1994 Calibration - 5 years
R-51B-001-C	Return to Agilent Warranty - 1 year
TG3	Tracking Generator, 3 GHz
TR1	Training kit, RF transceiver and courseware for education lab
UK6	Commercial calibration certificate with test data included
