RF Spectrum Analyzer
Created with Pixso. Keysight Agilent N9340B Handheld RF Spectrum Analyzer HSA 3 GHz

Keysight Agilent N9340B Handheld RF Spectrum Analyzer HSA 3 GHz

Brand Name: Agilent
Model Number: N9340B
MOQ: 1 set
Price: Negotiation
Payment Terms: T/T
Detail Information
Place of Origin:
Malaysia
Product Name:
Handheld Spectrum Analyzer
Frequency:
100 KHz - 3 GHz
Form Factor:
Handheld
Average Noise Level:
-144 DBm
Condition:
Pre-Owned
Functions:
Tested, In Full Working Conditions
Supply Ability:
in stock
Product Description
Keysight Agilent N9340B Handheld RF Spectrum Analyzer HSA 3 GHz

Description of Keysight Agilent N9340B

The Agilent N9340B handheld spectrum analyzer (HSA) puts the speed and performance of spectrum analysis in the hands of your field engineers. It provides powerful features for field applications. Plus, the HSA’s superior performance gives you confidence in field test results while the optimized user interface enhances field productivity.

  • Creates reliable, accurate, and detailed picture of your communication system
  • Provides superior sensitivity
  • Tailors to application-specific test needs with powerful optional features

1 - Low frequency performance enhancement options are available, see Option N9340B-IBC and N9340B-XDM.


Functionality

  • 100 kHz to 3 GHz (tunable to 9 kHz1)
  • Internal preamplifier option up to 3 GHz
  • Built-in tracking generator

Performance

  • -144 dBm displayed average noise level (DANL)
  • ±0.5 dB typical amplitude accuracy
  • +10 dBm third order intercept (TOI)
  • <0.1 s sweep time for 3 GHz full span

Measurement Applications and Software

  • High-accuracy power measurement with Agilent U2000 Series USB power sensors
  • Spectrum monitor with spectrogram display, record and playback
  • AM/FM and ASK/FSK modulation analysis
  • AM/FM IBOC spectrum analysis and xDSL interference analysis



List of Options
1DC Automotive 12V DC adaptor
1DN Automotive 12V DC charger
1TC Hard Transit Case
ADP Spare AC/DC adaptor
AMA AM/FM Modulation Analysis
BAT Spare Battery Pack
BCG External Battery Charger
DMA ASK/FSK Modulation Analysis
IBC N9340B with low frequency performance enhancement and AM/FM In-Band On-Channel IBOC Measurement
INM Spectrogram Monitoring
PA3 Add 3GHz pre-amplifier
PLG Continental European power cord - ONLY FOR EU DISTR W MULT PWR CORD STANDARDS
R-50C-011-3 Agilent Calibration - 3 years
R-50C-011-5 Agilent Calibration - 5 years
R-50C-021-3 ANSI Z540-1-1994 Calibration - 3 years
R-50C-021-5 ANSI Z540-1-1994 Calibration - 5 years
R-51B-001-C Return to Agilent Warranty - 1 year
TAD Adaptor Type-N(m) 50 Ohm to Type-N (f) 75 Ohm DC to 1 GHz
TG3 Add 3GHz tracking generator
UK6 Commercial calibration certificate with test data included
XDM N9340B with low frequency performance enhancement and xDSL measurement capability


FAQ:



1.Can you ship order to Canada or Australia ?

Yes,we can .We send orders worldwide .

2. What delivery method do you use ? and delivery time ?

We can ship by EMS,DHL,FedEx,UPS,TNT with tracking number. Usual delivery time is 4-7 workdays.

3. What is your payment term?

100% T/T payment before shipment.

4. How can I ask any other question ?

You can contact us online or leave us messages below .
